Moteur
Type
Enduro / offroad
Cylindree
449.0 ccm (27.40 cubic inches)
Moteur
Single cylinder, four-stroke
Couple
41.3 Nm (4.2 kgf-m or 30.5 ft.lbs) @ 7000
Alésage x course
96.0 x 62.0 mm (3.8 x 2.4 inches)
Soupapes/cylindre
4
Compression
12.0:1
Refroidissement
Liquid
Alimentation
Carburettor. Keihin 40mm flat-slide carburetor with Throttle Position Sensor (TPS)
Distribution
Single Overhead Cams (SOHC)
Allumage
CD with electronic advance and lighting coil
Transmission
Boite de vitesses
5-speed
Transmission
Chain (final drive)
Démarrage
Electric & kick
Châssis & Suspension
Cadre
Semi-double cradle, aluminium twin-spar
Suspension avant
47mm inverted Showa cartridge fork with 16-position rebound and 16-position compression-damping adjustability
Débattement avant
315 mm (12.4 inches)
Suspension arrière
Pro-Link Showa single shock with adjustable spring-preload, 17-position rebound-damping adjustability, and compression-damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)
Débattement arrière
315 mm (12.4 inches)
Frein avant
Double disc
Frein arrière
Single disc
Pneu avant
80/100-21
Pneu arrière
110/100-18
Dimensions & Poids
Empattement
1478 mm (58.2 inches)
Hauteur selle
963 mm (37.9 inches) If adjustable, lowest setting.
Garde au sol
345 mm (13.6 inches)
Poids total
122.0 kg (269.0 pounds)
Réservoir
7.19 litres (1.90 US gallons)
