Moteur
Type
Sport
Cylindree
599.0 ccm (36.55 cubic inches)
Moteur
In-line four, four-stroke
Puissance
102.0 HP (74.5 kW)) @ 12000 RPM
Couple
64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 10500 RPM
Alésage x course
67.0 x 0.0 mm (2.6 x inches)
Soupapes/cylindre
4
Compression
12.0:1
Refroidissement
Liquid
Alimentation
Injection. PGM-FI
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Allumage
Computer-controlled digital transistorised with electronic advance
Lubrification
Wet sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Wet, multiple discs. Mechanical, cable-actuated.
Châssis & Suspension
Cadre
Aluminium, Backbone
Suspension avant
41mm tension and preload adjustable inverted HMAS cartridge-type telescopic fork,
Débattement avant
120 mm (4.7 inches)
Suspension arrière
Monoshock damper with adjustable tension and preload,
Débattement arrière
128 mm (5.0 inches)
Frein avant
Double disc. Optional ABS. Three-piston calipers, floating rotors and sintered metal pads
Frein arrière
Single disc. Optional ABS. Single-piston caliper and sintered metal pads
Pneu avant
120/70-ZR17
Pneu arrière
180/55-ZR17
Dimensions & Poids
Hauteur selle
800 mm (31.5 inches) If adjustable, lowest setting.
Garde au sol
135 mm (5.3 inches)
Longueur totale
2150 mm (84.6 inches)
Largeur totale
740 mm (29.1 inches)
Hauteur totale
1150 mm (45.3 inches)
Poids total
198.0 kg (436.5 pounds)
Réservoir
19.00 litres (5.02 US gallons)
