Moteur
Type
Touring
Cylindree
798.0 ccm (48.69 cubic inches)
Moteur
Twin, four-stroke
Puissance
83.8 HP (61.2 kW)) @ 8000 RPM
Couple
86.0 Nm (8.8 kgf-m or 63.4 ft.lbs) @ 5800 RPM
Alésage x course
82.0 x 75.6 mm (3.2 x 3.0 inches)
Soupapes/cylindre
4
Compression
12.0:1
Refroidissement
Liquid
Alimentation
Injection. Electronic intake pipe injection / digital engine management (BMS-K)
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Belt (final drive)
Embrayage
Multiple-disc clutch in oil bath, mechanically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Bridge-type aluminium frame, load-bearing engine
Suspension avant
Telescopic fork, 43 mm
Débattement avant
140 mm (5.5 inches)
Suspension arrière
Cast aluminium single-sided swing arm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Débattement arrière
140 mm (5.5 inches)
Frein avant
Double disc. ABS.
Frein arrière
Single disc. ABS.
Pneu avant
120/70-ZR17
Pneu arrière
180/55-ZR17
Dimensions & Poids
Empattement
1466 mm (57.7 inches)
Hauteur selle
840 mm (33.1 inches) If adjustable, lowest setting.
Longueur totale
2082 mm (82.0 inches)
Largeur totale
860 mm (33.9 inches)
Hauteur totale
1155 mm (45.5 inches)
Poids à sec
182.0 kg (401.2 pounds)
Poids total
204.0 kg (449.7 pounds)
Réservoir
16.00 litres (4.23 US gallons)
Performances & Homologation
Consommation
3.40 litres/100 km (29.4 km/l or 69.18 mpg)
Émissions
78.9 CO2 g/km. (CO2 - Carbon dioxide emission)
