Moteur
Type
Enduro / offroad
Cylindree
1170.0 ccm (71.39 cubic inches)
Moteur
Two cylinder boxer, two-stroke
Puissance
48.0 HP (35.0 kW)) @ 7750 RPM
Couple
120.0 Nm (12.2 kgf-m or 88.5 ft.lbs) @ 6000 RPM
Alésage x course
101.0 x 73.0 mm (4.0 x 2.9 inches)
Compression
12.0:1
Refroidissement
Oil & air
Alimentation
Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin spark ignition
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Shaft drive (cardan) (final drive)
Châssis & Suspension
Cadre
Two-section frame consisting of front and rear sections, load- bearing engine-gearbox unit
Suspension avant
BMW Motorrad Telelever
Débattement avant
210 mm (8.3 inches)
Suspension arrière
Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Débattement arrière
220 mm (8.7 inches)
Frein avant
Double disc. Optional integral ABS. Can be switched off.
Frein arrière
Single disc. Optional integral ABS. Can be switched off.
Pneu avant
110/80-R19
Pneu arrière
150/70-R17
Dimensions & Poids
Empattement
1510 mm (59.4 inches)
Hauteur selle
890 mm (35.0 inches) If adjustable, lowest setting.
Longueur totale
2240 mm (88.2 inches)
Poids à sec
223.0 kg (491.6 pounds)
Poids total
256.0 kg (564.4 pounds)
Performances & Homologation
Consommation
4.60 litres/100 km (21.7 km/l or 51.13 mpg)
Émissions
106.7 CO2 g/km. (CO2 - Carbon dioxide emission)
