Moteur
Type
Enduro / offroad
Cylindree
798.0 ccm (48.69 cubic inches)
Moteur
Twin, four-stroke
Puissance
85.0 HP (62.0 kW)) @ 7500 RPM
Couple
83.0 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 5750 RPM
Alésage x course
82.0 x 75.6 mm (3.2 x 3.0 inches)
Soupapes/cylindre
4
Compression
12.0:1
Refroidissement
Liquid
Alimentation
Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Mechanically operated multidisc wet clutch
Démarrage
Electric
Châssis & Suspension
Cadre
Tubular steel space frame, load-bearing engine
Suspension avant
Upside-down telescopic fork, 43 mm
Débattement avant
230 mm (9.1 inches)
Suspension arrière
Cast aluminium dual swing arm, WAD strut (travel related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Débattement arrière
215 mm (8.5 inches)
Frein avant
Double disc. ABS. Floating discs. Two-piston calipers.
Frein arrière
Single disc. ABS. Floating disc. Single-piston caliper.
Pneu avant
90/90-21
Pneu arrière
150/70-17
Dimensions & Poids
Empattement
1573 mm (61.9 inches)
Hauteur selle
880 mm (34.6 inches) If adjustable, lowest setting.
Longueur totale
2300 mm (90.6 inches)
Largeur totale
945 mm (37.2 inches)
Hauteur totale
1350 mm (53.1 inches)
Poids total
217.0 kg (478.4 pounds)
Réservoir
16.00 litres (4.23 US gallons)
Performances & Homologation
Consommation
4.30 litres/100 km (23.3 km/l or 54.70 mpg)
Émissions
99.8 CO2 g/km. (CO2 - Carbon dioxide emission)
