Moteur
Type
Enduro / offroad
Cylindree
853.0 ccm (52.05 cubic inches)
Moteur
Twin, four-stroke
Puissance
77.0 HP (56.2 kW)) @ 7500 RPM
Couple
83.0 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 6500 RPM
Alésage x course
84.0 x 77.0 mm (3.3 x 3.0 inches)
Soupapes/cylindre
4
Compression
12.7:1
Refroidissement
Liquid
Alimentation
Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Multiple-disc clutch in oil bath, mechanically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Bridge-type frame, steel shell construction
Suspension avant
Telescopic fork, 41 mm
Débattement avant
151 mm (5.9 inches)
Suspension arrière
Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Débattement arrière
171 mm (6.7 inches)
Frein avant
Double disc. ABS. Floating discs. Two-piston calipers.
Frein arrière
Single disc. ABS. Floating disc. Single-piston caliper.
Pneu avant
110/80-R19
Pneu arrière
150/70-R17
Dimensions & Poids
Empattement
1559 mm (61.4 inches)
Hauteur selle
815 mm (32.1 inches) If adjustable, lowest setting.
Longueur totale
2280 mm (89.8 inches)
Largeur totale
922 mm (36.3 inches)
Hauteur totale
1225 mm (48.2 inches)
Poids total
224.0 kg (493.8 pounds)
Réservoir
15.00 litres (3.96 US gallons)
Performances & Homologation
Vitesse max
190.0 km/h (118.1 mph)
Consommation
4.10 litres/100 km (24.4 km/l or 57.37 mpg)
Émissions
95.1 CO2 g/km. (CO2 - Carbon dioxide emission)
