Moteur
Type
Enduro / offroad
Cylindree
853.0 ccm (52.05 cubic inches)
Moteur
Twin, four-stroke
Puissance
95.0 HP (69.3 kW)) @ 8250 RPM
Couple
92.0 Nm (9.4 kgf-m or 67.9 ft.lbs) @ 6250 RPM
Alésage x course
84.0 x 77.0 mm (3.3 x 3.0 inches)
Soupapes/cylindre
4
Compression
12.7:1
Refroidissement
Liquid
Alimentation
Injection
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Multiple-disc clutch in oil bath, mechanically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Bridge-type frame, steel shell construction
Suspension avant
Upside-down telescopic fork, Ø 43 mm
Débattement avant
204 mm (8.0 inches)
Suspension arrière
Cast aluminium dual swing arm, central WAD spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable
Débattement arrière
219 mm (8.6 inches)
Frein avant
Double disc. ABS. Floating discs. Two-piston calipers.
Frein arrière
Single disc. ABS. Floating disc. Single-piston caliper.
Pneu avant
110/80-19
Pneu arrière
150/70-R17
Dimensions & Poids
Empattement
1559 mm (61.4 inches)
Hauteur selle
860 mm (33.9 inches) If adjustable, lowest setting.
Longueur totale
2280 mm (89.8 inches)
Largeur totale
922 mm (36.3 inches)
Hauteur totale
1225 mm (48.2 inches)
Poids total
229.0 kg (504.9 pounds)
Réservoir
15.00 litres (3.96 US gallons)
Performances & Homologation
Vitesse max
200.0 km/h (124.3 mph)
Consommation
4.10 litres/100 km (24.4 km/l or 57.37 mpg)
Émissions
95.1 CO2 g/km. (CO2 - Carbon dioxide emission)
