Moteur
Type
Enduro / offroad
Cylindree
853.0 ccm (52.05 cubic inches)
Moteur
Twin, four-stroke
Puissance
90.0 HP (65.7 kW)) @ 8000 RPM
Couple
86.0 Nm (8.8 kgf-m or 63.4 ft.lbs) @ 6250 RPM
Alésage x course
84.0 x 77.0 mm (3.3 x 3.0 inches)
Soupapes/cylindre
4
Compression
12.7:1
Refroidissement
Liquid
Alimentation
Injection
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Multiple-disc clutch in oil bath, mechanically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Tubular steel space, load bearing engine
Suspension avant
Upside-down telescopic fork, Ø 43 mm
Débattement avant
230 mm (9.1 inches)
Suspension arrière
Cast aluminium dual swing arm, central WAD spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable
Débattement arrière
215 mm (8.5 inches)
Frein avant
Double disc. Switchable ABS. Floating discs. Two-piston calipers.
Frein arrière
Single disc. Switchable ABS. Floating disc. Single-piston caliper.
Pneu avant
90/90-21
Pneu arrière
150/70-R17
Dimensions & Poids
Empattement
1593 mm (62.7 inches)
Hauteur selle
875 mm (34.4 inches) If adjustable, lowest setting.
Longueur totale
2300 mm (90.6 inches)
Largeur totale
939 mm (37.0 inches)
Hauteur totale
1437 mm (56.6 inches)
Poids total
244.0 kg (537.9 pounds)
Réservoir
23.00 litres (6.08 US gallons)
Performances & Homologation
Vitesse max
197.0 km/h (122.4 mph)
Consommation
4.10 litres/100 km (24.4 km/l or 57.37 mpg)
Émissions
95.1 CO2 g/km. (CO2 - Carbon dioxide emission)
