Moteur
Type
Naked bike
Cylindree
848.0 ccm (51.74 cubic inches)
Moteur
Two cylinder boxer, four-stroke
Puissance
70.0 HP (51.1 kW)) @ 7000 RPM
Couple
75.5 Nm (7.7 kgf-m or 55.7 ft.lbs) @ 5500 RPM
Alésage x course
87.5 x 70.5 mm (3.4 x 2.8 inches)
Soupapes/cylindre
4
Compression
10.3:1
Refroidissement
Air
Alimentation
Injection
Distribution
Overhead Cams (OHC)
Transmission
Boite de vitesses
5-speed
Transmission
Shaft drive (cardan) (final drive)
Embrayage
Single-disc dry clutch, hydraulically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Three-section composite frame consisting of front and rear section, load bearing engine.
Suspension avant
BMW Motorrad Telelever; stanchion diameter 35 mm, central strut, rebound damping adjustable
Débattement avant
120 mm (4.7 inches)
Suspension arrière
Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever; central strut, spring pre-load adjustable to continuously variable levels by means of hydraulic handwheel, rebound damping adjustable
Débattement arrière
130 mm (5.1 inches)
Frein avant
Dual disc
Frein arrière
Single disc
Pneu avant
120/70-ZR17
Pneu arrière
160/60-ZR18
Dimensions & Poids
Empattement
1487 mm (58.5 inches)
Hauteur selle
780 mm (30.7 inches) If adjustable, lowest setting.
Longueur totale
2170 mm (85.4 inches)
Largeur totale
940 mm (37.0 inches)
Hauteur totale
1220 mm (48.0 inches)
Poids à sec
214.0 kg (471.8 pounds)
Poids total
235.0 kg (518.1 pounds)
Réservoir
21.00 litres (5.55 US gallons)
Performances & Homologation
Vitesse max
190.0 km/h (118.1 mph)
Consommation
5.90 litres/100 km (16.9 km/l or 39.87 mpg)
Émissions
136.9 CO2 g/km. (CO2 - Carbon dioxide emission)
