Moteur
Type
Naked bike
Cylindree
1170.0 ccm (71.39 cubic inches)
Moteur
Two cylinder boxer, four-stroke
Puissance
109.0 (79.6 )) @ 7000
Couple
115.3 Nm (11.8 kgf-m or 85.0 ft.lbs) @ 6500
Alésage x course
101.0 x 73.0 mm (4.0 x 2.9 inches)
Soupapes/cylindre
4
Compression
12.0:1
Refroidissement
Oil & air
Alimentation
Injection. Electronic intake pipe injection / digital engine management system: BMS-O with throttle-by-wire
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Shaft drive (cardan) (final drive)
Embrayage
Single-disc dry clutch, hydraulically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Tubular space
Suspension avant
Upside-down fork, diameter 45 mm, spring pre-load adjustable, rebound and compression adjustable
Débattement avant
119 mm (4.7 inches)
Suspension arrière
Cast aluminum single-sided swing arm with Paralever brace, central progressive spring strut, spring pre-load adjustable, rebound damping adjustable
Débattement arrière
119 mm (4.7 inches)
Frein avant
Double disc. ABS. Four-piston calipers.
Frein arrière
Single disc. ABS. Floating calipers. Two-piston.
Pneu avant
120/70-ZR17
Pneu arrière
180/55-ZR17
Dimensions & Poids
Empattement
1519 mm (59.8 inches)
Hauteur selle
795 mm (31.3 inches) If adjustable, lowest setting.
Longueur totale
2129 mm (83.8 inches)
Largeur totale
1069 mm (42.1 inches)
Hauteur totale
871 mm (34.3 inches)
Poids total
220.0 kg (485.0 pounds)
Réservoir
15.90 litres (4.20 US gallons)
Performances & Homologation
Vitesse max
215.7 km/h (134.0 mph)
