Moteur
Type
Touring
Cylindree
1649.0 ccm (100.62 cubic inches)
Moteur
In-line six, four-stroke
Puissance
160.0 HP (116.8 kW)) @ 7750 RPM
Couple
175.0 Nm (17.8 kgf-m or 129.1 ft.lbs) @ 5250 RPM
Alésage x course
72.0 x 67.5 mm (2.8 x 2.7 inches)
Soupapes/cylindre
4
Compression
12.2:1
Refroidissement
Liquid
Alimentation
Injection. Electronic intake pipe injection, digital engine management (BMS-X)
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Shaft drive (cardan) (final drive)
Embrayage
Multiple-disc clutch in oil bath
Démarrage
Electric
Châssis & Suspension
Cadre
Bridge-type frame, cast aluminium, load bearing engine
Suspension avant
BMW Motorrad Duolever
Débattement avant
125 mm (4.9 inches)
Suspension arrière
Travel front/rear:
Débattement arrière
135 mm (5.3 inches)
Frein avant
Double disc. Four-piston calipers.
Frein arrière
Single disc. Two-piston calipers.
Pneu avant
120/70-ZR17
Pneu arrière
190/55-ZR17
Dimensions & Poids
Empattement
1680 mm (66.1 inches)
Hauteur selle
810 mm (31.9 inches) If adjustable, lowest setting.
Longueur totale
2324 mm (91.5 inches)
Largeur totale
1000 mm (39.4 inches)
Hauteur totale
1440 mm (56.7 inches)
Poids à sec
295.0 kg (650.4 pounds)
Poids total
319.0 kg (703.3 pounds)
Réservoir
24.00 litres (6.34 US gallons)
Performances & Homologation
Consommation
4.50 litres/100 km (22.2 km/l or 52.27 mpg)
Émissions
104.4 CO2 g/km. (CO2 - Carbon dioxide emission)
