Moteur
Type
Naked bike
Cylindree
1293.0 ccm (78.90 cubic inches)
Moteur
In-line four, four-stroke
Puissance
173.0 HP (126.3 kW)) @ 9250 RPM
Couple
140.0 Nm (14.3 kgf-m or 103.3 ft.lbs) @ 8250 RPM
Alésage x course
80.0 x 64.3 mm (3.1 x 2.5 inches)
Soupapes/cylindre
4
Compression
13.0:1
Refroidissement
Liquid
Alimentation
Injection. Electronic intake pipe injection/digital engine management including knock sensor (BMS-K)
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Lubrification
Dry sump
Transmission
Boite de vitesses
6-speed
Transmission
Shaft drive (cardan) (final drive)
Embrayage
Multiple-disc clutch in oil bath, hydraulically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Bridge-type, cast aluminium, load bearing engine
Suspension avant
BMW Motorrad Duolever; central spring strut
Débattement avant
115 mm (4.5 inches)
Suspension arrière
Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Débattement arrière
135 mm (5.3 inches)
Frein avant
Double disc. Optional ABS
Frein arrière
Single disc. Optional ABS
Pneu avant
120/70-ZR17
Pneu arrière
180/55-ZR17
Dimensions & Poids
Empattement
1585 mm (62.4 inches)
Hauteur selle
790 mm (31.1 inches) If adjustable, lowest setting.
Longueur totale
2228 mm (87.7 inches)
Largeur totale
856 mm (33.7 inches)
Hauteur totale
1095 mm (43.1 inches)
Poids à sec
214.0 kg (471.8 pounds)
Poids total
243.0 kg (535.7 pounds)
Réservoir
19.00 litres (5.02 US gallons)
Performances & Homologation
Vitesse max
200.0 km/h (124.3 mph)
Consommation
5.00 litres/100 km (20.0 km/l or 47.04 mpg)
Émissions
116.0 CO2 g/km. (CO2 - Carbon dioxide emission)
