Moteur
Type
Sport touring
Cylindree
1130.0 ccm (68.95 cubic inches)
Moteur
Two cylinder boxer, four-stroke
Puissance
85.0 HP (62.0 kW)) @ 7000 RPM
Couple
97.6 Nm (10.0 kgf-m or 72.0 ft.lbs) @ 5500 RPM
Alésage x course
70.5 x 75.0 mm (2.8 x 3.0 inches)
Soupapes/cylindre
4
Compression
11.5:1
Refroidissement
Liquid
Alimentation
Injection
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Transmission
Boite de vitesses
6-speed
Transmission
Shaft drive (cardan) (final drive)
Embrayage
Single-disc dry clutch, hydraulically operated
Démarrage
Electric
Châssis & Suspension
Cadre
Bridging frame consisting of die-cast aluminium, engine decoupled from vibration through bearings.
Suspension avant
BMW Motorrad Telelever; stanchion diameter 35 mm, central strut.
Débattement avant
115 mm (4.5 inches)
Suspension arrière
Die-cast aluminium single-sided swing arm with BMW Motorrad Paralever; central strut, spring preload adjustable to continuously variable levels by means of hydraulic handwheel, rebound damping adjustable.
Débattement arrière
150 mm (5.9 inches)
Frein avant
Double disc
Frein arrière
Single disc
Pneu avant
120/70-ZR17
Pneu arrière
180/55-ZR17
Dimensions & Poids
Empattement
1509 mm (59.4 inches)
Hauteur selle
840 mm (33.1 inches) If adjustable, lowest setting.
Longueur totale
2260 mm (89.0 inches)
Largeur totale
920 mm (36.2 inches)
Hauteur totale
1340 mm (52.8 inches)
Poids à sec
249.0 kg (549.0 pounds)
Poids total
300.0 kg (661.4 pounds)
Réservoir
22.00 litres (5.81 US gallons)
Performances & Homologation
Vitesse max
200.0 km/h (124.3 mph)
Consommation
5.00 litres/100 km (20.0 km/l or 47.04 mpg)
Émissions
116.0 CO2 g/km. (CO2 - Carbon dioxide emission)
