FLSTF Fat Boy
Harley-Davidson

FLSTF Fat Boy

1999-2011 · 1338.0 ccm (81.64 cubic inches) cc · V2, four-stroke
Moteur
Type Custom / cruiser
Cylindree 1338.0 ccm (81.64 cubic inches)
Moteur V2, four-stroke
Puissance 56.0 HP (40.9 kW)) @ 5000 RPM
Couple 97.0 Nm (9.9 kgf-m or 71.5 ft.lbs) @ 2350 RPM
Alésage x course 88.8 x 108.0 mm (3.5 x 4.3 inches)
Soupapes/cylindre 2
Compression 8.5:1
Refroidissement Air
Alimentation Carburettor
Distribution Overhead Valves (OHV)
Allumage Single-fire, non-wasted, map-controlled spark ignition
Lubrification Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump.
Transmission
Boite de vitesses 5-speed
Transmission Belt   (final drive)
Embrayage  Wet 9-plate
Démarrage Electric
Châssis & Suspension
Cadre Mild steel tubular frame; rectangular section backbone;
Suspension avant 41.3 mm
Débattement avant 129 mm (5.1 inches)
Suspension arrière Hidden, horizontal-mounted, coil-over shock
Débattement arrière 103 mm (4.1 inches)
Frein avant Single disc. Four-piston calipers.
Frein arrière Single disc. Four-piston calipers.
Pneu avant 130/90-16
Pneu arrière 130/90-16
Dimensions & Poids
Empattement 1632 mm (64.3 inches)
Hauteur selle 680 mm (26.8 inches) If adjustable, lowest setting.
Garde au sol 130 mm (5.1 inches)
Longueur totale 2395 mm (94.3 inches)
Poids à sec 310.0 kg (683.4 pounds)
Poids total 305.0 kg (672.4 pounds)
Réservoir 15.90 litres (4.20 US gallons)
Performances & Homologation
Vitesse max 152.0 km/h (94.4 mph)
Consommation 5.80 litres/100 km (17.2 km/l or 40.56 mpg)
Émissions 134.6 CO2 g/km. (CO2 - Carbon dioxide emission)
FLSTF Fat Boy

Plan d'entretien de référence Données constructeur

Source : Harley-Davidson (programme d'entretien type - V-twin courroie)

Moteur
Vidange huile moteur + filtre
Tous les 8 000 km ou 12 mois
Bougies - remplacer
Tous les 32 000 km
Filtre a air - controler/remplacer
Tous les 8 000 km ou 12 mois
Jeu aux soupapes / poussoirs - controler
Tous les 16 000 km
Ralenti / injection - controle
Tous les 8 000 km ou 12 mois
Lubrification
Huile de carter primaire - vidange
Tous les 16 000 km ou 24 mois
Huile de boite de vitesses - vidange
Tous les 32 000 km ou 24 mois
Transmission (courroie)
Courroie finale - tension/etat
Tous les 8 000 km ou 12 mois
Courroie finale - remplacer
Tous les 100 000 km
Embrayage - controle/reglage
Tous les 16 000 km ou 24 mois
Freins
Plaquettes frein avant - usure
Tous les 8 000 km ou 12 mois
Plaquettes frein arriere - usure
Tous les 8 000 km ou 12 mois
Liquide de frein (DOT) - changer
Tous les 24 mois
Suspension & Direction
Huile de fourche - remplacer
Tous les 24 mois
Roulements colonne de direction - controle
Tous les 16 000 km ou 24 mois
Roues & Pneus
Pression pneus - controler
Tous les 1 000 km ou 1 mois
Usure pneus - controler
Tous les 8 000 km ou 6 mois
Electricite
Batterie - controler
Tous les 12 mois
Eclairage et signalisation
Tous les 8 000 km ou 12 mois
General
Serrage boulonnerie - controler
Tous les 8 000 km ou 12 mois
