Moteur
Type
Custom / cruiser
Cylindree
1499.0 ccm (91.47 cubic inches)
Moteur
V2, four-stroke
Puissance
67.0 HP (48.9 kW)) @ 5200 RPM
Couple
110.0 Nm (11.2 kgf-m or 81.1 ft.lbs) @ 3100 RPM
Alésage x course
95.3 x 101.6 mm (3.8 x 4.0 inches)
Soupapes/cylindre
2
Compression
8.8:1
Refroidissement
Air
Alimentation
Carburettor
Distribution
Overhead Valves (OHV)
Allumage
Single-fire, non-wasted, map-controlled spark ignition.
Lubrification
Dry sump. Internally mounted, crank driven gerotor pressure and dual scavenge pump.
Transmission
Boite de vitesses
5-speed
Transmission
Belt (final drive)
Embrayage
Multi-plate clutch with diaphragm spring in oil bath
Démarrage
Electric
Châssis & Suspension
Cadre
Steel, square-section backbone with twin downtubes.
Suspension avant
41.3mm Telescopic forks
Débattement avant
117 mm (4.6 inches)
Suspension arrière
Dual air adjustable shocks
Débattement arrière
76 mm (3.0 inches)
Frein avant
Dual disc
Frein arrière
Single disc
Pneu avant
MT90-B16
Pneu arrière
MU85-B16
Dimensions & Poids
Empattement
1612 mm (63.5 inches)
Hauteur selle
692 mm (27.2 inches) If adjustable, lowest setting.
Garde au sol
130 mm (5.1 inches)
Longueur totale
2440 mm (96.1 inches)
Poids à sec
345.0 kg (760.6 pounds)
Poids total
345.0 kg (760.6 pounds)
Réservoir
18.90 litres (4.99 US gallons)
Performances & Homologation
Vitesse max
165.0 km/h (102.5 mph)
Consommation
5.34 litres/100 km (18.7 km/l or 44.05 mpg)
Émissions
123.9 CO2 g/km. (CO2 - Carbon dioxide emission)
