CVO Breakout
Harley-Davidson

CVO Breakout

2013-2014 · 1802.7 ccm (110.00 cubic inches) cc · V2, four-stroke
Moteur
Type Custom / cruiser
Cylindree 1802.7 ccm (110.00 cubic inches)
Moteur V2, four-stroke
Puissance 80.0 HP (58.4 kW)) @ 5100 RPM
Couple 151.9 Nm (15.5 kgf-m or 112.0 ft.lbs) @ 3500 RPM
Alésage x course 101.6 x 111.3 mm (4.0 x 4.4 inches)
Soupapes/cylindre 2
Compression 9.2:1
Refroidissement Air
Alimentation Injection
Distribution Overhead Valves (OHV)
Allumage Single-fire, non-wasted, map-controlled spark ignition
Transmission
Boite de vitesses 6-speed
Transmission Belt   (final drive)
Embrayage Multi-plate with diaphragm spring in oil bath
Démarrage Electric
Châssis & Suspension
Cadre Tubular steel. Rectangular section backbone. MIG-welded-
Suspension avant 41.3 mm telescopic, chrome dust covers,
Débattement avant 143 mm (5.6 inches)
Suspension arrière Hidden, horizontal-mounted, coil-over,
Débattement arrière 91 mm (3.6 inches)
Frein avant Single disc. Four-piston calipers.
Frein arrière Single disc. Two-piston calipers.
Pneu avant 130/60-B21
Pneu arrière 240/40-R18
Dimensions & Poids
Empattement 1709 mm (67.3 inches)
Hauteur selle 630 mm (24.8 inches) If adjustable, lowest setting.
Garde au sol 107 mm (4.2 inches)
Longueur totale 2446 mm (96.3 inches)
Poids à sec 316.6 kg (698.0 pounds)
Poids total 330.2 kg (728.0 pounds)
Réservoir 18.93 litres (5.00 US gallons)
Performances & Homologation
Consommation 5.23 litres/100 km (19.1 km/l or 44.98 mpg)
Émissions 121.3 CO2 g/km. (CO2 - Carbon dioxide emission)
CVO Breakout

Plan d'entretien de référence Données constructeur

Source : Harley-Davidson (programme d'entretien type - V-twin courroie)

Moteur
Vidange huile moteur + filtre
Tous les 8 000 km ou 12 mois
Bougies - remplacer
Tous les 32 000 km
Filtre a air - controler/remplacer
Tous les 8 000 km ou 12 mois
Jeu aux soupapes / poussoirs - controler
Tous les 16 000 km
Ralenti / injection - controle
Tous les 8 000 km ou 12 mois
Lubrification
Huile de carter primaire - vidange
Tous les 16 000 km ou 24 mois
Huile de boite de vitesses - vidange
Tous les 32 000 km ou 24 mois
Transmission (courroie)
Courroie finale - tension/etat
Tous les 8 000 km ou 12 mois
Courroie finale - remplacer
Tous les 100 000 km
Embrayage - controle/reglage
Tous les 16 000 km ou 24 mois
Freins
Plaquettes frein avant - usure
Tous les 8 000 km ou 12 mois
Plaquettes frein arriere - usure
Tous les 8 000 km ou 12 mois
Liquide de frein (DOT) - changer
Tous les 24 mois
Suspension & Direction
Huile de fourche - remplacer
Tous les 24 mois
Roulements colonne de direction - controle
Tous les 16 000 km ou 24 mois
Roues & Pneus
Pression pneus - controler
Tous les 1 000 km ou 1 mois
Usure pneus - controler
Tous les 8 000 km ou 6 mois
Electricite
Batterie - controler
Tous les 12 mois
Eclairage et signalisation
Tous les 8 000 km ou 12 mois
General
Serrage boulonnerie - controler
Tous les 8 000 km ou 12 mois
