Moteur
Type
Scooter
Cylindree
493.0 ccm (30.08 cubic inches)
Moteur
Single cylinder, four-stroke
Puissance
40.0 HP (29.2 kW)) @ 7250 RPM
Couple
42.5 Nm (4.3 kgf-m or 31.3 ft.lbs) @ 5200 RPM
Alésage x course
94.0 x 71.0 mm (3.7 x 2.8 inches)
Soupapes/cylindre
4
Compression
10.0:1
Refroidissement
Liquid
Alimentation
Injection
Distribution
Single Overhead Cams (SOHC)
Allumage
Double ignition
Transmission
Boite de vitesses
Automatic
Transmission
Chain (final drive)
Embrayage
Dry centrifugal type with damping plugs
Démarrage
Electric
Châssis & Suspension
Cadre
Double cradle trellis made of high strength steel tubes
Suspension avant
Parallelogram composed of four aluminium arms supporting two steering tubes, cantilevered suspension. Electro-hydraulic suspension locking system.
Débattement avant
85 mm (3.3 inches)
Suspension arrière
Oscillating engine fixed to the frame with a swingarm and two dual effect hydraulic shock absorbers with four-position spring preload.
Débattement arrière
110 mm (4.3 inches)
Frein avant
Double disc. Two-piston caliper
Frein arrière
Single disc. Two-piston caliper
Pneu avant
120/70-12
Pneu arrière
140/70-14
Dimensions & Poids
Empattement
1550 mm (61.0 inches)
Hauteur selle
785 mm (30.9 inches) If adjustable, lowest setting.
Longueur totale
2210 mm (87.0 inches)
Largeur totale
790 mm (31.1 inches)
Poids à sec
244.0 kg (537.9 pounds)
Poids total
244.0 kg (537.9 pounds)
Réservoir
12.00 litres (3.17 US gallons)
Performances & Homologation
Vitesse max
145.0 km/h (90.1 mph)
Consommation
4.76 litres/100 km (21.0 km/l or 49.42 mpg)
Émissions
110.4 CO2 g/km. (CO2 - Carbon dioxide emission)
