Moteur
Type
Scooter
Cylindree
152.0 ccm (9.28 cubic inches)
Moteur
Single cylinder, four-stroke
Puissance
10.6 HP (7.7 kW)) @ 7750 RPM
Couple
10.5 Nm (1.1 kgf-m or 7.7 ft.lbs) @ 6000 RPM
Alésage x course
59.5 x 54.8 mm (2.3 x 2.2 inches)
Soupapes/cylindre
2
Compression
12.0:1
Refroidissement
Liquid
Alimentation
Carburettor. TK D26
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Allumage
Electronic, capacitive discharge
Lubrification
Wet sump
Transmission
Boite de vitesses
Automatic
Transmission
Belt (final drive)
Embrayage
Automatic centrifugal
Démarrage
Electric
Châssis & Suspension
Cadre
Triangular trellis with extra double cradle, in high-tensile steel tubing, welded in robotized block. Steering head inclination 26°
Suspension avant
Ceriani leading axle telehydraulic fork, with aluminium sleeves, rod diam. 33 mm, wheel travel 97 mm
Débattement avant
95 mm (3.7 inches)
Suspension arrière
Engine casing acting as swing-arm, with extra support arm on the right side
Débattement arrière
127 mm (5.0 inches)
Frein avant
Single disc
Frein arrière
Single disc
Pneu avant
120/70-13
Pneu arrière
140/70-12
Dimensions & Poids
Empattement
1400 mm (55.1 inches)
Hauteur selle
818 mm (32.2 inches) If adjustable, lowest setting.
Longueur totale
1910 mm (75.2 inches)
Hauteur totale
1200 mm (47.2 inches)
Poids à sec
122.0 kg (269.0 pounds)
Poids total
129.0 kg (284.4 pounds)
Réservoir
11.70 litres (3.09 US gallons)
