Moteur
Type
Enduro / offroad
Cylindree
505.0 ccm (30.82 cubic inches)
Moteur
Single cylinder, four-stroke
Puissance
59.7 HP (43.6 kW)) @ 8500 RPM
Couple
50.0 Nm (5.1 kgf-m or 36.9 ft.lbs) @ 5750 RPM
Alésage x course
104.0 x 59.5 mm (4.1 x 2.3 inches)
Soupapes/cylindre
4
Compression
11.5:1
Alimentation
Injection. Electronic injection - throttle body 42 mm EURO 3
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Allumage
Digital
Lubrification
Wet sump and reeds
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Wet clutch 7 steel discs
Démarrage
Electric & kick
Châssis & Suspension
Cadre
Single tube cradle with forged, casted and extruded elements and carbon structural part s.
Suspension avant
50 mm fully adjustable
Suspension arrière
Sachs shock absorber fully adjustable
Frein avant
Single disc
Frein arrière
Single disc
Pneu avant
80/100-21
Pneu arrière
140/80-18
Dimensions & Poids
Empattement
1450 mm (57.1 inches)
Hauteur selle
960 mm (37.8 inches) If adjustable, lowest setting.
Longueur totale
2160 mm (85.0 inches)
Largeur totale
810 mm (31.9 inches)
Hauteur totale
1240 mm (48.8 inches)
Poids à sec
110.0 kg (242.5 pounds)
Réservoir
9.00 litres (2.38 US gallons)
