Moteur
Type
Naked bike
Cylindree
125.0 ccm (7.63 cubic inches)
Moteur
Single cylinder, four-stroke
Puissance
11.1 HP (8.1 kW)) @ 9500 RPM
Couple
10.0 Nm (1.0 kgf-m or 7.4 ft.lbs) @ 7000 RPM
Alésage x course
54.0 x 54.5 mm (2.1 x 2.1 inches)
Soupapes/cylindre
4
Compression
9.8:1
Refroidissement
Oil & air
Alimentation
Injection. Electronic fuel injection with throttle body d.28
Distribution
Single Overhead Cams (SOHC)
Allumage
Delphi MT05
Lubrification
Forced lubrication with wet sump
Transmission
Boite de vitesses
5-speed
Transmission
Chain (final drive)
Embrayage
Wet
Démarrage
Electric
Châssis & Suspension
Cadre
Trestle in steel tubes
Suspension avant
Upside - down forks,.35mm
Débattement avant
111 mm (4.4 inches)
Suspension arrière
Swing arm with central shock absorber with spring pre-load adjustment
Débattement arrière
40 mm (1.6 inches)
Frein avant
Single disc. CBS
Frein arrière
Single disc
Pneu avant
110/80-17
Pneu arrière
130/70-17
Dimensions & Poids
Empattement
1360 mm (53.5 inches)
Hauteur selle
770 mm (30.3 inches) If adjustable, lowest setting.
Garde au sol
190 mm (7.5 inches)
Longueur totale
2050 mm (80.7 inches)
Largeur totale
810 mm (31.9 inches)
Hauteur totale
1065 mm (41.9 inches)
Poids à sec
142.0 kg (313.1 pounds)
Poids total
142.0 kg (313.1 pounds)
Réservoir
13.50 litres (3.57 US gallons)
Performances & Homologation
Consommation
1.70 litres/100 km (58.8 km/l or 138.37 mpg)
Émissions
39.4 CO2 g/km. (CO2 - Carbon dioxide emission)
