Moteur
Type
Super motard
Cylindree
749.9 ccm (45.76 cubic inches)
Moteur
V2, four-stroke
Puissance
92.0 HP (67.2 kW)) @ 8750 RPM
Couple
82.0 Nm (8.4 kgf-m or 60.5 ft.lbs) @ 4500 RPM
Alésage x course
92.0 x 56.4 mm (3.6 x 2.2 inches)
Soupapes/cylindre
4
Compression
11.0:1
Refroidissement
Liquid
Alimentation
Injection. Integrated engine management system. Electronic fuel injection with ride-by-wire electronic throttle control.
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Allumage
Digital electronic, integrated in the fuel injection system.
Lubrification
Wet sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Hydraulically operated multi-plate wet clutch.
Démarrage
Electric
Châssis & Suspension
Cadre
Modular steel trellis secured to aluminium side plates by high strength bolts. Detachable rear frame.
Suspension avant
43 mm upside-down fork.
Débattement avant
160 mm (6.3 inches)
Suspension arrière
Aluminium alloy swingarm.
Débattement arrière
160 mm (6.3 inches)
Frein avant
Double disc. ABS
Frein arrière
Single disc. ABS
Pneu avant
120/70-17
Pneu arrière
180/55-17
Dimensions & Poids
Empattement
1505 mm (59.3 inches)
Hauteur selle
870 mm (34.3 inches) If adjustable, lowest setting.
Longueur totale
2216 mm (87.2 inches)
Largeur totale
905 mm (35.6 inches)
Hauteur totale
1185 mm (46.7 inches)
Poids à sec
186.0 kg (410.1 pounds)
Réservoir
12.00 litres (3.17 US gallons)
