Moteur
Type
Scooter
Cylindree
102.0 ccm (6.22 cubic inches)
Moteur
Single cylinder, four-stroke
Puissance
7.0 HP (5.1 kW)) @ 7000 RPM
Couple
7.9 Nm (0.8 kgf-m or 5.8 ft.lbs) @ 5000 RPM
Alésage x course
50.0 x 52.0 mm (2.0 x 2.0 inches)
Compression
9.0:1
Refroidissement
Air
Alimentation
Carburettor
Distribution
Overhead Cams (OHC)
Allumage
Capacitor Discharge Ignition
Transmission
Boite de vitesses
4-speed
Transmission
Shaft drive (cardan) (final drive)
Embrayage
Dry Automatic Centrefugal Clutch
Démarrage
Electric
Châssis & Suspension
Suspension avant
Bottom Link with Spring-loaded Hydraulic Damper
Suspension arrière
Swing Arm with Spring-loaded Hydraulic Damper
Frein avant
Expanding brake (drum brake). Internal Expanding Shoe Type (130mm) Non-asbestos Type
Frein arrière
Expanding brake (drum brake). Internal Expanding Shoe Type (130mm) Non-asbestos Type
Pneu avant
3.5-10
Pneu arrière
3.5-10
Dimensions & Poids
Empattement
1240 mm (48.8 inches)
Hauteur selle
805 mm (31.7 inches) If adjustable, lowest setting.
Garde au sol
125 mm (4.9 inches)
Longueur totale
1750 mm (68.9 inches)
Largeur totale
705 mm (27.8 inches)
Hauteur totale
1100 mm (43.3 inches)
Poids à sec
104.0 kg (229.3 pounds)
Poids total
104.0 kg (229.3 pounds)
Réservoir
5.00 litres (1.32 US gallons)
Performances & Homologation
Vitesse max
77.0 km/h (47.8 mph)
