Moteur
Type
Naked bike
Cylindree
1078.0 ccm (65.78 cubic inches)
Moteur
V2, four-stroke
Puissance
98.0 HP (71.5 kW)) @ 7500 RPM
Couple
105.0 Nm (10.7 kgf-m or 77.4 ft.lbs) @ 5500 RPM
Alésage x course
98.0 x 71.5 mm (3.9 x 2.8 inches)
Soupapes/cylindre
2
Compression
10.7:1
Refroidissement
Oil & air
Alimentation
Injection
Distribution
Desmodromic valve control
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Dry Clutch, multi-disc
Démarrage
Electric
Châssis & Suspension
Cadre
CNC milled aluminium plates, Chrome-molybdenum gridframe and carbon fibre
Suspension avant
Extreme Tech tension loaded, adj. traction and compression unit
Suspension arrière
Extreme Tech adjustable traction and compression unit, Pre-loaded spring
Frein avant
Double disc. Bremo 4-piston, four separates pads, radial pump
Frein arrière
Single disc. Bremo, 2-piston
Pneu avant
120/70-ZR17
Pneu arrière
180/55-ZR17
Dimensions & Poids
Empattement
1390 mm (54.7 inches)
Hauteur selle
800 mm (31.5 inches) If adjustable, lowest setting.
Longueur totale
2100 mm (82.7 inches)
Largeur totale
700 mm (27.6 inches)
Hauteur totale
1120 mm (44.1 inches)
Poids à sec
167.0 kg (368.2 pounds)
Réservoir
16.00 litres (4.23 US gallons)
