Moteur
Type
Naked bike
Cylindree
1198.0 ccm (73.10 cubic inches)
Moteur
V2, four-stroke
Puissance
162.0 HP (118.2 kW)) @ 9500 RPM
Couple
131.0 Nm (13.4 kgf-m or 96.6 ft.lbs) @ 7700 RPM
Alésage x course
106.0 x 67.9 mm (4.2 x 2.7 inches)
Soupapes/cylindre
4
Compression
11.5:1
Refroidissement
Liquid
Alimentation
Injection. Electronic fuel injection Bimota by Athena
Distribution
Desmodromic valve control
Lubrification
Wet sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Multi-plate clutch in oil bath
Démarrage
Electric
Châssis & Suspension
Cadre
NiCrMo4 steel and aluminium plates
Suspension avant
Ohlins 43mm preload -fully adjustable and DLC treated upside-down forks
Suspension arrière
Ohlins preload-fully adjustable top and lower speed monoshock
Frein avant
Double disc. Brembo calipers four pistons, four separates pads, radial pump.
Frein arrière
Single disc. Brembo 2-pistons
Pneu avant
120/70-ZR17
Pneu arrière
190/55-ZR17
Dimensions & Poids
Empattement
1435 mm (56.5 inches)
Hauteur selle
800 mm (31.5 inches) If adjustable, lowest setting.
Longueur totale
2040 mm (80.3 inches)
Largeur totale
730 mm (28.7 inches)
Hauteur totale
1105 mm (43.5 inches)
Poids à sec
177.0 kg (390.2 pounds)
Réservoir
18.00 litres (4.76 US gallons)
Performances & Homologation
Vitesse max
260.0 km/h (161.6 mph)
