Moteur
Type
Naked bike
Cylindree
999.6 ccm (61.00 cubic inches)
Moteur
V4, four-stroke
Puissance
167.3 HP (122.1 kW)) @ 11500 RPM
Couple
111.5 Nm (11.4 kgf-m or 82.2 ft.lbs) @ 9500 RPM
Alésage x course
78.0 x 52.3 mm (3.1 x 2.1 inches)
Soupapes/cylindre
4
Compression
13.0:1
Refroidissement
Liquid
Alimentation
Injection. Airbox with front dynamic air intakes. 4 Weber-Marelli 48-mm throttle bodies with 4 injectors and latest generation Ride-by-Wire engine management. Choice of three different engine maps selectable by the rider with bike in motion: T (Track), S (Sport), R
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Allumage
Magneti Marelli digital electronic ignition system integrated in engine control system, with one spark plug per cylinder and “stick-coil” type coils
Lubrification
Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Multiplate wet clutch with mechanical slipper system.
Démarrage
Electric
Châssis & Suspension
Cadre
Aluminium dual beam chassis with cast and pressed sheet elements. (Sachs steering damper on APRC version)
Suspension avant
Sachs upside down front fork with diam. 43 mm stanchions. Forged aluminium calliper mountings for radial callipers. Completely adjustable spring preload and hydraulic compression and rebound damping.
Débattement avant
120 mm (4.7 inches)
Suspension arrière
Sachs piggy back monoshock with completely adjustable: spring preload and hydraulic compression and rebound damping. APS progressive linkage
Débattement arrière
130 mm (5.1 inches)
Frein avant
Double disc. ABS. Floating stainless steel discs with lightweight stainless steel rotor with 6 studs. Brembo radial callipers with 4 diam. horizontally opposed 32 mm pistons. Sintered pads. Axial pump master cylinder and metal braided brake hoses.
Frein arrière
Single disc. ABS. Brembo floating calliper with two and #61638;32 mm isolated pistons. Pump with integrated tank and metal braided hose.
Pneu avant
120/70-ZR17
Pneu arrière
190/55-ZR17
Dimensions & Poids
Empattement
1445 mm (56.9 inches)
Hauteur selle
835 mm (32.9 inches) If adjustable, lowest setting.
Garde au sol
125 mm (4.9 inches)
Longueur totale
2065 mm (81.3 inches)
Hauteur totale
1090 mm (42.9 inches)
Poids à sec
183.0 kg (403.4 pounds)
Réservoir
17.00 litres (4.49 US gallons)
Performances & Homologation
Consommation
8.07 litres/100 km (12.4 km/l or 29.15 mpg)
Émissions
187.2 CO2 g/km. (CO2 - Carbon dioxide emission)
