Moteur
Type
Scooter
Cylindree
49.4 ccm (3.01 cubic inches)
Moteur
Single cylinder, two-stroke
Alésage x course
40.0 x 39.3 mm (1.6 x 1.5 inches)
Compression
12.5:1
Refroidissement
Liquid
Alimentation
Injection. DITECH Electronic Direct Injection
Allumage
High power inductive
Lubrification
Injection with electronic oil pump
Transmission
Transmission
Chain (final drive)
Embrayage
Automatic centrifugal dry clutch
Démarrage
Electric
Châssis & Suspension
Cadre
Split single-cradlle in high tensile tubular steel
Suspension avant
Telescopic hydraulic fork mounted on offset steering stem.
Débattement avant
90 mm (3.5 inches)
Suspension arrière
Engine functions as swinging fork swingarm, linked to the frame by dual connecting rods and two radial silent blocks.
Débattement arrière
70 mm (2.8 inches)
Frein avant
Single disc
Frein arrière
Single disc
Pneu avant
130/60-13
Pneu arrière
130/60-13
Dimensions & Poids
Empattement
1340 mm (52.8 inches)
Hauteur selle
678 mm (26.7 inches) If adjustable, lowest setting.
Garde au sol
250 mm (9.8 inches)
Longueur totale
1865 mm (73.4 inches)
Largeur totale
770 mm (30.3 inches)
Hauteur totale
1410 mm (55.5 inches)
Réservoir
9.30 litres (2.46 US gallons)
