Moteur
Type
Enduro / offroad
Cylindree
50.0 ccm (3.05 cubic inches)
Moteur
Single cylinder, two-stroke
Alésage x course
39.9 x 40.0 mm (1.6 x 1.6 inches)
Compression
11.5:1
Refroidissement
Liquid
Alimentation
Carburettor. Electronically controlled Dell’Orto PHVA 17.5 carburettor
Allumage
Electronic with CDI capacity discharge
Lubrification
Automatic mixer
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Multiplate, wet
Démarrage
Kick
Châssis & Suspension
Cadre
Twin tube, steel
Suspension avant
Upside down fork with Ø 41 mm stanchions
Débattement avant
240 mm (9.4 inches)
Suspension arrière
Aluminium alloy swingarm, mono shock absorber with progressive link system
Débattement arrière
200 mm (7.9 inches)
Frein avant
Single disc. Stainless steel disc with floating calliper
Frein arrière
Single disc. Stainless steel disc with floating calliper
Pneu avant
80/90-21
Pneu arrière
110/80-18
Dimensions & Poids
Empattement
1395 mm (54.9 inches)
Hauteur selle
880 mm (34.6 inches) If adjustable, lowest setting.
Longueur totale
2105 mm (82.9 inches)
Largeur totale
840 mm (33.1 inches)
Poids total
104.0 kg (229.3 pounds)
Réservoir
7.00 litres (1.85 US gallons)
Performances & Homologation
Consommation
2.96 litres/100 km (33.8 km/l or 79.47 mpg)
Émissions
68.7 CO2 g/km. (CO2 - Carbon dioxide emission)
