Moteur
Type
Sport
Cylindree
124.2 ccm (7.58 cubic inches)
Moteur
Single cylinder, four-stroke
Puissance
14.8 HP (10.8 kW)) @ 10000 RPM
Couple
11.2 Nm (1.1 kgf-m or 8.3 ft.lbs) @ 8000 RPM
Alésage x course
58.0 x 47.0 mm (2.3 x 1.9 inches)
Soupapes/cylindre
4
Compression
12.6:1
Refroidissement
Liquid
Alimentation
Carburettor
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Allumage
ECU Electronics Magneti Marelli MIUG4 ø 32 mm
Lubrification
Wet sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Multiple discs, in oil bath
Démarrage
Electric
Châssis & Suspension
Cadre
Aluminium perimeter
Suspension avant
Upside down hydraulic fork, 40 mm.
Débattement avant
110 mm (4.3 inches)
Suspension arrière
Asymmetrical swingarm, monoshock absorber
Débattement arrière
120 mm (4.7 inches)
Frein avant
Single disc. ABS. Stainless steel disc with radial 4 piston calliper
Frein arrière
Single disc. Stainless steel disc and calliper with single 30 mm piston.
Pneu avant
100/80-ZR17
Pneu arrière
140/70-ZR17
Dimensions & Poids
Empattement
1353 mm (53.3 inches)
Hauteur selle
820 mm (32.3 inches) If adjustable, lowest setting.
Longueur totale
1968 mm (77.5 inches)
Largeur totale
760 mm (29.9 inches)
Hauteur totale
1135 mm (44.7 inches)
Poids à sec
117.0 kg (257.9 pounds)
Poids total
144.0 kg (317.5 pounds)
Réservoir
14.50 litres (3.83 US gallons)
Performances & Homologation
Vitesse max
124.0 km/h (77.1 mph)
Consommation
2.60 litres/100 km (38.5 km/l or 90.47 mpg)
Émissions
60.3 CO2 g/km. (CO2 - Carbon dioxide emission)
