Moteur
Type
Super motard
Cylindree
896.1 ccm (54.68 cubic inches)
Moteur
V2, four-stroke
Puissance
95.2 HP (69.5 kW)) @ 8750 RPM
Couple
90.0 Nm (9.2 kgf-m or 66.4 ft.lbs) @ 6500 RPM
Alésage x course
92.0 x 67.4 mm (3.6 x 2.7 inches)
Soupapes/cylindre
4
Compression
11.0:1
Refroidissement
Liquid
Alimentation
Injection. Integrated engine management system. Electronic fuel injection with ride-by-wire electronic throttle control.
Distribution
Double Overhead Cams/Twin Cam (DOHC)
Allumage
Digital electronic, integrated in the fuel injection system.
Lubrification
Wet sump
Transmission
Boite de vitesses
6-speed
Transmission
Chain (final drive)
Embrayage
Hydraulically operated multi-plate wet clutch.
Démarrage
Electric
Châssis & Suspension
Cadre
Modular tubular steel frame fastened to aluminium side plates by high strength bolts. Removable rear subframe.
Suspension avant
Kayaba upside-down fork, Ø 41 mm stanchions adjustable in preload and hydraulic rebound damping
Débattement avant
160 mm (6.3 inches)
Suspension arrière
Aluminium alloy swingarm Sachs monoshock absorber adjustable in preload and hydraulic rebound damping.
Débattement arrière
155 mm (6.1 inches)
Frein avant
Double disc. ABS.Stainless steel wave floating wave disc. 4-piston.
Frein arrière
Single disc. ABS. Four-piston radial calipers..
Pneu avant
120/70-ZR17
Pneu arrière
180/55-ZR17
Dimensions & Poids
Empattement
1515 mm (59.6 inches)
Hauteur selle
870 mm (34.3 inches) If adjustable, lowest setting.
Garde au sol
108 mm (4.3 inches)
Longueur totale
2210 mm (87.0 inches)
Largeur totale
905 mm (35.6 inches)
Hauteur totale
1185 mm (46.7 inches)
Poids à sec
195.0 kg (429.9 pounds)
Poids total
212.0 kg (467.4 pounds)
Réservoir
12.00 litres (3.17 US gallons)
Performances & Homologation
Consommation
5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Émissions
129.9 CO2 g/km. (CO2 - Carbon dioxide emission)
